Send InquiryVsole On Grid Inverter Single Phase 1 MPPT Inbuilt WiFi, 3.4 KW Capacity (VS-341S)
Price 16390.0 INR/ Piece
MOQ : 1 Piece
Vsole On Grid Inverter Single Phase 1 MPPT Inbuilt WiFi, 3.4 KW Capacity (VS-341S) Specification
- Features
- H bridge & T-type three-level topology & enhanced SPWM (Space Pulse Width Modulation).
- Efficiency
- 97.5 %
- Maintenance Type
- NA
- Input Voltage
- 3700 Watt (W)
- Product Type
- Other
- Material
- Na
- Number of Cells
- NA
- Power
- 3400 Watt (w)
- Operating Temperature
- -25 C ~ +65 C Celsius (oC)
- Max Voltage
- 550 Volt (V)
- Max System Voltage
- 550 Volt (V)
- Output Voltage
- 70-550 Volt (V)
- Cable Length
- NA Millimeter (mm)
- Switch Mode
- Other
- Size
- Standard
- Dimension (L*W*H)
- 280W*310H*184D Millimeter (mm)
- Color
- White
- Weight
- 6.35 Kilograms (kg)
- Warranty
- 10 Year
- Application
- Home, Industrial, Commercial
- Type Of Technology
- Other
- Installation Type
- Other
Vsole On Grid Inverter Single Phase 1 MPPT Inbuilt WiFi, 3.4 KW Capacity (VS-341S) Trade Information
- Minimum Order Quantity
- 1 Piece
- Payment Terms
- Paypal, Telegraphic Transfer (T/T)
- Supply Ability
- 1000 Pieces Per Month
- Delivery Time
- 7 Days
- Packaging Details
- National Standard Packaging
- Main Domestic Market
- All India
About Vsole On Grid Inverter Single Phase 1 MPPT Inbuilt WiFi, 3.4 KW Capacity (VS-341S)
Single Phase Grid Tie InverterVS (101S -361S) 1KW-3.6KW- DC overloading upto 10%.
- High DC/AC ratio for more yields.
- Max. DC input current per string; compatible upto 800WP solar panel.
- H bridge & T-type three-level topology & enhanced SPWM (Space Pulse Width Modulation).
- Special external colour with Epoxy Novolac coating for better Heat Management.
- Wide Input Range; Low Voltage start-up of 80V.
- Compact and light weight design for an easy Installation.
- Multiple MPPT Design with IDA Technology (Intelligent Disturbance Algorithm).
- Inbuilt surge protections at both AC and DC side.
- Fan-less natural cooling models.
- RS485, remote monitoring (Wi-Fi/GPRS).
- User friendly Web and Mobile App Monitoring.
- Zero export enabled models (External CT required).
