Deye 110kW On Grid Strind Inverter Three Phase

About Deye 110kW On Grid Strind Inverter Three Phase

Massive Utility-Scale Power & Efficiency: This series supports large-scale industrial projects by handling an impressive maximum PV input power of up to 150 kW , achieving a peak conversion efficiency of up to 98.8% and an MPPT efficiency greater than 99%. Up to 6 Independent MPP Trackers: It features up to 6 independent MPP trackers with a dense 4+4+4+4+4+4 string layout , providing maximum flexibility to harvest energy from complex, multi-angled commercial rooftops or large ground-mounted arrays. Smart Power Management: It comes with native support for Zero Export and Virtual Synchronous Generator (VSG) applications , allowing plant operators to efficiently regulate or restrict the amount of solar power fed back into the utility grid. Premium Hardware Protection: The series features built-in TYPE II surge protection devices (SPD) on both the DC and AC sides , an integrated DC Switch , and standard protection against reverse polarity, short circuits, and residual currents. Weatherproof and Quiet Active Cooling: It holds an IP65 ingress protection rating (noted as JP 65 in data) for reliable outdoor performance. It uses an Intelligent Air Cooling system to manage high thermal loads while keeping the operating noise low at $\le$ 55 dB. Versatile System Monitoring: It includes standard RS485 and RS232 communication interfaces alongside flexible optional monitoring modes, such as GPRS, WIFI, Bluetooth, 4G, and LAN, for seamless remote asset management. Wide Engineering Layout Window: It offers a wide MPPT operational voltage range of 200V to 850V with a maximum input tolerance of 1000V , giving system engineers the flexibility to design longer, highly cost-effective panel strings
