Vsole 10kw Solar Hybrid Inverter Single Phase Inverter (VS-HY10T-10KW 48V)

Price 168458.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Vsole 10kw Solar Hybrid Inverter Single Phase Inverter (VS-HY10T-10KW 48V) Specification

Efficiency
97.60%

Maintenance Type
Intelligent Cooling

Features
3 Stages/Equalization charging curve , self-adaptation to BMS for Li-ion battery , 0.9 leading to 0.9 lagging power factor adjustment, and single-phase unbalanced handling

Input Voltage
370 Watt (W)

Product Type
Other

Material
NA

Number of Cells
0

Power
10000 Watt (w)

Operating Temperature
-45 C to 60 C Celsius (oC)

Max Voltage
10000 Watt (W)

Max System Voltage
10000 Watt (W)

Output Voltage
220 / 230 Watt (W)

Cable Length
NA Millimeter (mm)

Switch Mode
Other

Size
420 670 223

Dimension (L*W*H)
420 670 223 Millimeter (mm)

Color
White

Weight
35.6 Kilograms (kg)

Warranty
10 Year

Application
Home, Industrial, Commercial

Type Of Technology
Other

Installation Type
Other

Vsole 10kw Solar Hybrid Inverter Single Phase Inverter (VS-HY10T-10KW 48V) Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Paypal, Telegraphic Transfer (T/T)

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

Sample Available
Yes

Packaging Details
national standard packaging

Main Domestic Market
All India

Certifications
Anti-islanding, PV String Input Reverse Polarity, Insulation Resistor Detection, Residual Current Monitoring Unit, Output Overcurrent, Output Shorted, Surge Protection, and Output Overvoltage Protection (DC Type II / AC Type III)

About Vsole 10kw Solar Hybrid Inverter Single Phase Inverter (VS-HY10T-10KW 48V)

The Vsole Solar Hybrid Inverter (VS-HY10T-10KW, 48V) is a powerful single-phase hybrid inverter designed for residential and small commercial solar systems, combining on-grid, off-grid, and battery backup functions in one integrated unit. It efficiently manages energy from solar panels, batteries, the utility grid, and even a diesel generator, ensuring continuous and reliable power supply with a super-fast switching time of around 4 milliseconds during outages. With a rated capacity of 10kW and a 48V battery system, it can handle heavy loads such as air conditioners, pumps, and multiple appliances while maintaining high efficiency of up to about 97.6%. The inverter supports dual MPPT technology for optimized solar energy harvesting and allows connection of up to around 12kW of solar panels, along with high charging/discharging current (around 220A) for faster battery performance. It is compatible with multiple battery types including lithium-ion, LiFePO4, and lead-acid, and features smart energy management with programmable priority settings (solar, battery, grid) and intelligent load control. Built with advanced protections like anti-islanding, overload, and short-circuit safety, along with a durable IP-rated design and LCD display, it ensures safe and easy operation. Additionally, it supports parallel operation of multiple units for system expansion and includes zero export functionality, making it an ideal solution for modern solar installations requiring scalability, reliability, and energy independence
