DEYE 10KW-48V/Three Phase Hybrid Inverter, 2 MPPT, Low Voltage Battery Supported

About DEYE 10KW-48V/Three Phase Hybrid Inverter, 2 MPPT, Low Voltage Battery Supported

The Deye SUN SG05LP3-EU-SM2 Series Three Phase Hybrid Solar Inverter is a powerful and intelligent energy solution designed for residential, commercial, and industrial solar systems. With a wide power range from 3kW to 12kW, this inverter offers exceptional flexibility, high efficiency, and reliable performance for modern energy needs.

Built to support 48V low-voltage battery systems, this inverter is compatible with both lithium-ion and lead-acid batteries, featuring an advanced self-adaptive BMS charging system for optimized battery performance and longer lifespan. With a maximum charging/discharging current of up to 240A, it ensures efficient energy storage and utilization.

The inverter supports up to 10 units in parallel, allowing scalable system expansion for large installations. It can also store energy from diesel generators, making it highly versatile for hybrid power setups and backup solutions.

Equipped with dual MPPT technology (up to 2 MPPT / 4 strings), the inverter maximizes solar energy generation even under complex rooftop conditions. It supports up to 24kW PV access power and operates within a wide MPPT voltage range of 200V650V, ensuring optimal solar performance.

One of its standout features is the ability to deliver 100% unbalanced output, allowing each phase to output up to 50% of the rated power, making it ideal for uneven load distribution across phases.

The inverter also supports AC coupling, enabling easy integration with existing solar systems. With 6 programmable time periods for battery charging and discharging, users can optimize energy usage and reduce electricity costs.

Designed for durability, the inverter features an IP65-rated enclosure, making it suitable for outdoor installations. It operates efficiently in extreme environments from -40C to +60C and uses intelligent air cooling for optimal thermal performance with low noise (55dB).

Safety is ensured with comprehensive protection features, including anti-islanding, surge protection (Type II AC/DC), short circuit protection, insulation monitoring, and optional arc fault detection.
