VS-HY75T-75KW Solar Hybrid Inverter Three Phase High Voltage Inverter

Send Inquiry

Request To Call Back

VS-HY75T-75KW Solar Hybrid Inverter Three Phase High Voltage Inverter

Name: VS-HY75T-75KW Solar Hybrid Inverter Three Phase High Voltage Inverter
Brand: LAVANCHA RENEWABLE ENERGY PRIVATE LIMITED
Price: 651925 INR
Availability: InStock

Price 651925 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

VS-HY75T-75KW Solar Hybrid Inverter Three Phase High Voltage Inverter Specification

Features
Hybrid Operation, High Voltage support, Remote Monitoring, 3 Phase Output, Multiple MPPT

Input Voltage
600-900V DC

Efficiency
98.2% Max

Maintenance Type
Low Maintenance

Product Type
Solar Hybrid Inverter

Material
Metal Body (Industrial Grade Components)

Power
75KW

Operating Temperature
-25C ~ 60C

Max Voltage
900V DC

Max System Voltage
1100V DC

Output Voltage
400V AC (Three Phase)

Cable Length
Customizable / As per Installation

Switch Mode
MPPT (Maximum Power Point Tracking)

Size
Standard Industrial

Dimension (L*W*H)
1000mm x 600mm x 230mm

Color
White & Blue

Weight
120kg

Application
Industrial, Commercial, Large Solar Power Systems

Type Of Technology
IGBT, MPPT, Transformerless

Installation Type
Wall Mounted/Floor Mounted

Communication Interface
RS485, CAN, WiFi (Optional)

Display
LCD Touchscreen

Certificates
IEC 62109, IEC 61683, CE Certified

Rated Output Frequency
50/60Hz (Auto Sensing)

Grid Type
On-Grid/Off-Grid with Battery Backup

Cooling
Smart Forced Air Cooling

Protection
Overload, Short Circuit, Reverse Polarity, Over Temp, Anti-Islanding

Battery Compatibility
Support for Lithium-ion, Lead-acid, and LiFePO4

VS-HY75T-75KW Solar Hybrid Inverter Three Phase High Voltage Inverter Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

Main Domestic Market
All India

VS-HY75T-75KW Solar Hybrid Inverter Three Phase High Voltage Inverter About

Discover the top-tier VS-HY75T-75KW Solar Hybrid Inverter-a redoubtable solution for industrial, commercial, and large solar power projects. Eminent for its hybrid operation and high voltage support, this inverter offers competitive pricing while allowing you to personalise cable length and installation type as per your requirements. Enjoy seamless reliability with LCD touchscreen, intelligent protections, and a smart forced air cooling system. Compatible with various battery types, it showcases remote monitoring, multiple MPPT, and transformerless technology-making it the preferred choice for discerning engineers and energy professionals across India.

Direction and Site of Application

The VS-HY75T-75KW Solar Hybrid Inverter is engineered for general and specific uses in industrial, commercial, and large solar power systems. Install the unit wall- or floor-mounted as per site conditions, ensuring it sits within the recommended temperature range. Apply in locations demanding robust three-phase power with high voltage and battery backup, such as factories, business parks, and renewable energy farms. Follow the supplied guidelines for optimal orientation and cable connections to achieve peak efficiency and long-term reliability.

Supply Ability and Certified Assurance

We respond promptly to your purchase order, providing a reliable exchange or supply process. The VS-HY75T-75KW inverter boasts comprehensive certifications, including IEC 62109, IEC 61683, and CE. Our sample policy ensures you can review quality before commitment, and supply ability meets diverse project scales across India. For detailed pricing or to discuss your asking price, contact us to start the process-assured by thorough compliance and eminent industry standards for every transaction.

FAQ's of VS-HY75T-75KW Solar Hybrid Inverter Three Phase High Voltage Inverter:

Q: How do I install the VS-HY75T-75KW Solar Hybrid Inverter for optimal results?

A: To install, position the inverter on a wall or floor in a ventilated area within the specified -25C to 60C temperature range. Adhere to provided wiring diagrams and safety protocols, ensuring customised cable lengths and battery types are correctly connected.

Q: What benefits does the hybrid operation of this inverter offer?

A: Hybrid operation enables seamless power management by combining on-grid and off-grid functions with battery backup. This ensures continuous supply, grid independence when needed, and maximised energy utilisation, particularly in industrial or commercial applications.

Q: Where is the best site to apply this inverter?

A: It is ideally suited for industrial and commercial sites, such as factories, office complexes, and large-scale solar power plants, where three-phase high voltage output and battery integration are essential.

Q: What protection features are integrated into the VS-HY75T-75KW?

A: The inverter includes overload, short circuit, reverse polarity, over-temperature, and anti-islanding protections to ensure the safety and longevity of both the system and connected loads.

Q: When should I consider sample review and what is the process?

A: Prior to full deployment, request a sample to review the inverter's features, installation requirements, and compatibility. Provide your purchase order to access supply and consult our sample policy for detailed steps.
