VS-HY40T-40KW Vsole 40kW Three Phase High Voltage Solar Hybrid Inverter

Send Inquiry

Request To Call Back

VS-HY40T-40KW Vsole 40kW Three Phase High Voltage Solar Hybrid Inverter

Name: VS-HY40T-40KW Vsole 40kW Three Phase High Voltage Solar Hybrid Inverter
Brand: LAVANCHA RENEWABLE ENERGY PRIVATE LIMITED
Price: 460347 INR
Availability: InStock

Price 460347 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

VS-HY40T-40KW Vsole 40kW Three Phase High Voltage Solar Hybrid Inverter Specification

Features
PV/AC/Genset/Hybrid Mode; Smart Monitoring; Lithium/Lead Acid Battery Compatible; Seamless Transition; Grid Feedback

Maintenance Type
Low Maintenance

Efficiency
98.2%

Input Voltage
180V-850V DC

Product Type
Three Phase High Voltage Solar Hybrid Inverter

Material
Metal Cabinet with Electronic Components

Number of Cells
N/A (Inverter does not use cells)

Power
40kW

Operating Temperature
-25C to 60C

Max Voltage
850V DC

Max System Voltage
1000V DC

Output Voltage
400V AC (Three Phase)

Cable Length
Customizable as per installation requirements

Switch Mode
Automatic / Manual

Size
Standard Industrial Size

Dimension (L*W*H)
735740240 mm

Color
White & Grey

Weight
84 kg

Application
Commercial, Industrial, Solar Power Plants

Type Of Technology
IGBT Based High Frequency Hybrid

Installation Type
Wall Mounted / Floor Mounted

Ingress Protection
IP65 Outdoor Rated

Overload Protection
Yes

Rated Output Current
57.8A

Max Parallel Units
Up to 6 Units Parallel

Display
LCD Touch Screen

Rated Battery Voltage
200-800V DC

Communication Interface
RS485/CAN/Ethernet/WiFi

Cooling Method
Smart Intelligent Fan Cooling

Frequency
50/60 Hz

Battery Type Compatibility
Lithium-ion, Lead Acid

Max PV Power
60kW

Noise Level
<60dB

Surge Protection
Integrated

MPPT Range
180V-850V DC

VS-HY40T-40KW Vsole 40kW Three Phase High Voltage Solar Hybrid Inverter Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About VS-HY40T-40KW Vsole 40kW Three Phase High Voltage Solar Hybrid Inverter

Highlighted by impeccable engineering and remarkable efficiency, the VS-HY40T-40KW Vsole 40kW Three Phase High Voltage Solar Hybrid Inverter offers a triumphant combination of power and versatility for commercial, industrial, and solar plant applications. Take advantage of its special rate and robust features, including 57.8A output, 60kW max PV power, and a wide MPPT range. This IP65-rated inverter ensures low maintenance, integrated surge and overload protection, and seamless transition between PV, AC, genset, and hybrid modes. With smart monitoring and outstanding battery compatibility, it sets the standard for reliability.

Harness Versatility for Demanding Applications

The VS-HY40T-40KW Vsole 40kW Three Phase High Voltage Solar Hybrid Inverter is engineered for specific usage in commercial, industrial, and solar power plant settings. Its remarkable flexibility supports PV/AC/genset/hybrid operation, seamlessly adapting to diverse energy needs. Featuring advanced smart monitoring, compatibility with both lithium-ion and lead acid batteries, and automatic/manual switch modes, this inverter transforms energy management for robust applications, ensuring unwavering performance and reliability across installations.

Streamlined Export, Packaging, and Order Handling

Our main export markets span India and global destinations, ensuring widespread availability of the VS-HY40T-40KW inverter. Packing & dispatch processes use secure, industry-grade packaging to protect goods during transport. Order processing is swift, with transparent tracking at every stage. Sample units are available upon request, optimizing your procurement experience. With careful packing and prompt goods transport, we guarantee the inverter arrives ready for seamless installation at your location.

FAQ's of VS-HY40T-40KW Vsole 40kW Three Phase High Voltage Solar Hybrid Inverter:

Q: How can the VS-HY40T-40KW Vsole inverter benefit commercial or industrial facilities?

A: This inverter offers robust 40kW power, seamless transition modes, and compatibility with multiple battery types, making it ideal for supporting reliable, efficient energy supply and grid feedback in large-scale operations.

Q: What protection features are included in the VS-HY40T-40KW inverter?

A: It comes equipped with integrated surge and overload protection, IP65 outdoor-rated casing, and a smart intelligent fan cooling system for impeccable operational safety and durability.

Q: Where can this inverter be installed, and what mounting options are available?

A: The inverter supports flexible installation, with both wall-mounted and floor-mounted options, suitable for outdoor or indoor use in various industrial or commercial settings.

Q: What is the process for sampling and ordering the VS-HY40T-40KW inverter?

A: You can request a sample unit to evaluate performance. Once your order is placed, our team manages packing, dispatch, and goods transport to ensure secure and timely delivery.

Q: Which communication interfaces does the inverter support for monitoring and integration?

A: The inverter features multiple interfaces-including RS485, CAN, Ethernet, and WiFi-enabling comprehensive smart monitoring and system integration for optimized energy management.
