VS-HY30T-30KW Three Phase High Voltage Solar Hybrid Inverter

Name: VS-HY30T-30KW Three Phase High Voltage Solar Hybrid Inverter
Brand: LAVANCHA RENEWABLE ENERGY PRIVATE LIMITED
Price: 386419 INR
Availability: InStock

Price 386419 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

VS-HY30T-30KW Three Phase High Voltage Solar Hybrid Inverter Specification

Efficiency
98.2%

Features
Hybrid operation, Grid-tied and Off-grid, High voltage support, Battery backup, Remote Monitoring

Maintenance Type
Low Maintenance

Input Voltage
160-950V DC

Product Type
Three Phase High Voltage Solar Hybrid Inverter

Material
Metal

Power
30KW

Operating Temperature
-25C to +60C

Max Voltage
1000V DC

Max System Voltage
1000V

Output Voltage
400V AC

Cable Length
Customizable

Switch Mode
Automatic

Size
Standard Industrial

Dimension (L*W*H)
700mm x 520mm x 288mm

Color
White

Weight
68kg

Application
Commercial & Industrial Solar Systems

Type Of Technology
IGBT Based

Installation Type
Floor or Wall Mounted

Communication Interface
RS485, CAN, Wi-Fi, Ethernet

Protection Features
Overvoltage, Overcurrent, Overtemperature, Short-circuit Protection, Surge Protection

Inverter Topology
Transformerless

Battery Type Supported
Lithium-ion, Lead-acid

Cooling Method
Smart Forced Air Cooling

Grid Type
Three Phase

Display
LCD Display with Remote Monitoring

Altitude
4000m (derating above 2000m)

Noise Level
<50dB

Relative Humidity
0-95% Non-condensing

Frequency
50/60Hz

MPPT Tracker
3 MPPT

VS-HY30T-30KW Three Phase High Voltage Solar Hybrid Inverter Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About VS-HY30T-30KW Three Phase High Voltage Solar Hybrid Inverter

The VS-HY30T-30KW Three Phase High Voltage Solar Hybrid Inverter is an acclaimed powerhouse for commercial and industrial solar systems, engineered for peak efficiency at 98.2%. Clients have remarked on its cost-effective hybrid operation, combining grid-tied and off-grid modes, while supporting scarce battery types like lithium-ion and lead-acid. Its transformerless IGBT technology ensures rapid, enlightened performance with smart cooling and versatile communication interfaces. Protection features guard against soaring electrical risks, making VS-HY30T-30KW a smart, reliable solution, even at altitudes up to 4000m, and adaptable for India's growing energy needs.

Powerful Performance & Versatile Application

The VS-HY30T-30KW Solar Hybrid Inverter is ideally applied in commercial and industrial settings for uninterrupted power supply. Installation is flexible-either floor or wall mounted-ensuring convenience on-site. Noted for its robust features, including three independent MPPT trackers, hybrid grid operation, high voltage support, and remote monitoring via LCD and wireless options, this machine stands out for reliability and functionality in challenging environments. Its user-friendly design and advanced protection measures make it the first choice for large-scale solar applications.

Sample Availability & Order Fulfilment

Samples of the VS-HY30T-30KW Inverter are available upon request, allowing for thorough evaluation prior to large orders. With strong supply ability, we can accommodate high-volume requirements, ensuring minimal delays. Payment terms are clearly structured, with all charges and sale prices transparently communicated at the initial stage. Prompt dispatching is assured, ensuring clients receive their products swiftly and reliably, making the procurement process seamless and trustworthy for traders and service providers alike.

FAQ's of VS-HY30T-30KW Three Phase High Voltage Solar Hybrid Inverter:

Q: How can the VS-HY30T-30KW inverter be integrated into existing commercial solar systems?

A: The VS-HY30T-30KW inverter supports transformerless technology and offers multiple communication interfaces like RS485, CAN, Wi-Fi, and Ethernet, making it easy to connect with existing infrastructure. Its adaptability to both grid-tied and off-grid systems allows seamless integration with current commercial solar arrays.

Q: What are the main benefits of choosing this inverter for industrial applications?

A: This inverter offers high efficiency (98.2%), advanced protection features, support for high voltage operations, and compatibility with lithium-ion or lead-acid batteries. These attributes deliver cost-effective performance and enhanced reliability in demanding industrial scenarios.

Q: When is it advisable to use the hybrid operation feature?

A: Hybrid operation is recommended when both grid availability and energy storage are required, ensuring continuous power supply during outages or periods of high demand, thus optimizing the use of available solar and stored energy.

Q: Where can the VS-HY30T-30KW inverter be installed?

A: The inverter is designed for both indoor floor and wall mounting in commercial or industrial facilities. Its durable metal construction and wide operating temperature range make it suitable for varied installation environments across India.

Q: What steps are involved in the process of ordering samples or bulk units?

A: To order a sample or bulk purchase, clients can contact the supplier or service provider directly. After discussing specific requirements, charges, and sale prices, the order is promptly processed and dispatched, with flexible payment terms and supply commitments clearly communicated.

Q: How does remote monitoring work with this machine?

A: Remote monitoring is enabled through integrated Wi-Fi, Ethernet, and other communication interfaces, allowing users to track performance, status, and system alerts from a distance via an LCD display or connected devices.
