TopCon Bi-Facial Non-DCR Solar Panel

Get a Price/Quote

MOQ : 10 Watts

TopCon Bi-Facial Non-DCR Solar Panel Specification

Product Type
Bi-Facial Non-DCR Solar Panel

Material
Mono-crystalline Silicon

Number of Cells
144 (6x24)

Operating Temperature
-40C to +85C

Max Voltage
42.04 V

Max System Voltage
1500 V DC

Panel Efficiency
21.5 %

Cable Length
1.2 Meter

Number Of Diodes
3

Maximum Snow Load
5400 Pa

Size
High Power (210mm cell)

Dimension (L*W*H)
2278 mm x 1134 mm x 30 mm

Weight
29.5 kg

Color
Silver Frame / Transparent Backsheet

Connector
MC4 Compatible

Bifacial Gain (Up to)
25 % additional power

Front Power Output (STC)
570 Wp

Wind Load
2400 Pa

Fire Type
Class C

Frame
Anodized Aluminium Alloy

Glass
2.0 mm + 2.0 mm, High-transmittance, Tempered glass

Application
Utility, Commercial, Rooftop, Ground Mount

Manufacturing Origin
India

Junction Box
IP68 Rated, Split-type, 3 diodes

Product Code
TopCon Bi-Facial-570W

Cell Type
N-type TOPCon Bi-facial

Module Efficiency (Bifacial)
Up to 27 % with rear side

TopCon Bi-Facial Non-DCR Solar Panel Trade Information

Minimum Order Quantity
10 Watts

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Watts Per Month

Delivery Time
7 Days

Main Domestic Market
All India

TopCon Bi-Facial Non-DCR Solar Panel About

Get It Now: the acclaimed TopCon Bi-Facial Non-DCR Solar Panel, designed for triumphant energy solutions. With an imposing 570 Wp front output and up to 25% additional bifacial gain, this first-rate panel achieves module efficiency up to 27%-delivering maximum power from both sides. Its robust construction includes N-type TOPCon bi-facial cells, an IP68 split-type junction box, and 2.0mm high-transmittance tempered glass. Supported by an anodized aluminium alloy frame, this mono-crystalline silicon module excels in fire safety (Class C), wind, and snow load. Manufactured in India for superior performance.

Premium Material & Versatile Applications

Crafted from mono-crystalline silicon and encased in a sturdy anodized aluminium alloy frame, the TopCon Bi-Facial Non-DCR Solar Panel is truly first-rate. This robust build allows it to be used for utility, commercial, rooftop, and ground-mount installations. Its impressive bifacial technology maximizes sunlight capture at multiple sites, making it suitable for a broad range of applications and environments demanding long-lasting and efficient power solutions.

Certifications, Logistics, and Market Reach

Every TopCon Bi-Facial Non-DCR Solar Panel is handover-ready-with certifications that ensure top-tier quality and safety. The official sale price and quotation can be obtained with straightforward processes, and FOB port shipping ensures efficient logistics. Widely available across the main domestic market in India, this panel is a preferred choice among suppliers, traders, and service providers looking for reliable renewable energy solutions.

FAQ's of TopCon Bi-Facial Non-DCR Solar Panel:

Q: How does the TopCon Bi-Facial Solar Panel achieve up to 27% module efficiency?

A: The TopCon Bi-Facial Solar Panel utilizes advanced N-type TOPCon bi-facial cells, enabling it to capture sunlight from both the front and rear sides, thereby achieving a combined module efficiency of up to 27% with bifacial gain.

Q: What are the main benefits of using a bi-facial solar panel for my project?

A: Bi-facial solar panels like the TopCon 570W model generate additional power by absorbing reflected sunlight from the rear side, boosting total energy output by up to 25%. This results in higher overall efficiency and greater energy savings.

Q: Where can I install the TopCon Bi-Facial Non-DCR Solar Panel?

A: This imposing panel is suitable for utility, commercial, rooftop, and ground-mount applications. Its robust build and weather resistance make it an excellent choice for various installation sites.

Q: When can I request a quotation or initiate purchase for this product?

A: Quotations and sale price information for the TopCon Bi-Facial Solar Panel can be requested at any time from the supplier, trader, or service provider in India, with a prompt and straightforward handover process.

Q: What certification standards does this solar panel comply with?

A: The TopCon Bi-Facial Solar Panel meets recognized safety and quality certifications, including an IP68 rated junction box and Class C fire rating, meeting industry standards for reliability and operation.
