TITAN Series TSUN 2250W-3000W Single Phase Microinverter

Send Inquiry

Request To Call Back

TITAN Series TSUN 2250W-3000W Single Phase Microinverter

Name: TITAN Series TSUN 2250W-3000W Single Phase Microinverter
Brand: LAVANCHA RENEWABLE ENERGY PRIVATE LIMITED
Price: 49000 INR
Availability: InStock

Price 49000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TITAN Series TSUN 2250W-3000W Single Phase Microinverter Specification

Efficiency
Max 96.7%

Input Voltage
16V-60V DC

Maintenance Type
Low, remote monitoring enabled

Features
IP67 waterproof; High reliability; Independent MPPT for Each Module; Online Monitoring Capability

Product Type
Single Phase Microinverter

Material
Aluminum Alloy

Number of Cells
Up to 6 PV Modules

Power
2250W-3000W

Operating Temperature
-40C to +65C

Max Voltage
60V DC

Max System Voltage
600V

Output Voltage
230V

Cable Length
2.3m

Switch Mode
Automatic

Size
Compact

Dimension (L*W*H)
398 x 242 x 47 mm

Color
Silver

Weight
5.8 kg

Application
Residential and Commercial Solar System

Type Of Technology
Microinverter Technology

Installation Type
On-grid, rooftop or ground mount

Communication
2.4 GHz wireless, optional RS485/CAN

Surge Protection
Integrated

Input Current Max
14A per channel

Protection Features
Over/Under Voltage Protection, Over Temperature Protection, Anti-Islanding

Enclosure Protection
IP67

MPPT Voltage Range
16V-60V

Grid Frequency
50/60 Hz

Start-up Voltage
22V

Cooling Method
Natural Convection (fanless)

Night Power Consumption
<50mW

TITAN Series TSUN 2250W-3000W Single Phase Microinverter Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

Main Domestic Market
All India

TITAN Series TSUN 2250W-3000W Single Phase Microinverter About

Unlock a premier solar experience with the TITAN Series TSUN 2250W-3000W Single Phase Microinverter, crafted for excellence with unrivaled efficiency and unparalleled reliability. This spectacular microinverter features state-of-the-art Markdown technology and supports up to 6 PV modules. Enjoy robust protection, high waterproof IP67 rating, and natural fanless cooling. Seamless integration with on-grid residential and commercial solar systems is made popular by remote monitoring and versatile 2.4 GHz wireless communication. The TSUN microinverter delivers unmatched performance, making it the optimal choice for your solar power needs in India.

Application and Surface Versatility

The TITAN Series TSUN 2250W-3000W Microinverter is built for diverse application media, including rooftops and ground-mounted solar installations. Its robust aluminum alloy body and IP67 enclosure ensure reliability across various surfaces and plant applications. Designed to operate efficiently in both residential and commercial solar plants, this compact device maximizes energy conversion while seamlessly adapting to the installed environment, offering consistent high performance regardless of site conditions.

Sample Policy, Delivery & Certifications

Take advantage of our sample policy to evaluate the TITAN Series at the lowest price before full-scale deployment. Shipped goods are handled with care, and prompt delivery times ensure fast project kick-off. Our products come with required certifications and quality assurances meaningful to service providers, suppliers, and traders across India. Freight terms are customer-friendly, promising a transparent, value-driven buying experience for all solar system stakeholders.

FAQ's of TITAN Series TSUN 2250W-3000W Single Phase Microinverter:

Q: How do you install the TITAN Series TSUN 2250W-3000W Microinverter in a solar system?

A: Installation is straightforward and flexible, allowing for on-grid, rooftop, or ground-mount applications. The compact design and 2.3m cable facilitate easy attachment to solar panels, and the automatic switch mode simplifies grid integration.

Q: What protection features does the TSUN microinverter offer?

A: The TSUN microinverter is equipped with over/under voltage protection, over temperature protection, anti-islanding, and integrated surge protection, ensuring safe and trouble-free operation in diverse environments.

Q: When can I expect delivery and what certifications are provided?

A: Typically, delivery is prompt following order confirmation, with all shipped goods protected during transit. Each microinverter is supplied with authentic certifications, ensuring high quality and compliance with industry standards.

Q: Where is the TSUN microinverter most effectively used?

A: This microinverter excels in both residential and commercial solar system projects across India, performing reliably on various surfaces such as rooftops and ground-mounted arrays.

Q: What is the process for remote monitoring and maintenance?

A: The microinverter features online monitoring via 2.4 GHz wireless communication or optional RS485/CAN, allowing easy tracking of performance metrics and streamlined maintenance, all without the need for on-site visits.

Q: Which benefits does the independent MPPT provide for each module?

A: Independent MPPT for each module ensures optimal energy production by maximizing the output of every connected solar panel, resulting in increased overall system efficiency, especially under partially shaded conditions.
