SUN-M40G4-EU-Q0-1 Deye 400W Single Phase Microinverter

Send Inquiry

Request To Call Back

SUN-M40G4-EU-Q0-1 Deye 400W Single Phase Microinverter

Name: SUN-M40G4-EU-Q0-1 Deye 400W Single Phase Microinverter
Brand: LAVANCHA RENEWABLE ENERGY PRIVATE LIMITED
Price: 49000 INR
Availability: InStock

Price 49000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

SUN-M40G4-EU-Q0-1 Deye 400W Single Phase Microinverter Specification

Maintenance Type
Low maintenance required

Features
IP67 waterproof, Monitoring via APP, Plug-and-play, Rapid Shutdown, Lightweight design, High reliability

Efficiency
Max. 96.5%

Input Voltage
16-60V DC

Product Type
Microinverter

Material
ABS+PC/AL alloy

Power
400W

Operating Temperature
-40C to +65C

Max Voltage
60V

Max System Voltage
60V

Output Voltage
230V AC

Cable Length
2.5 m

Switch Mode
Automatic

Size
27619633.7 mm

Dimension (L*W*H)
27619633.7 mm

Color
Black & Silver

Weight
2.8 kg

Application
Residential & commercial solar PV installations

Type Of Technology
Microinverter Technology

Installation Type
On-grid/rooftop

Peak Power Tracking
Yes, Integrated MPPT

Output Power Factor
>0.99

MPPT Voltage Range
16-60V

Cooling Method
Natural convection

Communication
2.4G wireless, Optional WiFi/PLC

Protection Functions
Over/under voltage, Over temperature, Islanding, Short circuit, Reverse polarity

Nominal Output Current
1.74A

Safety Standards
EN 62109-1, EN 62109-2, EN 61000-6-1/-2/-3/-4

Maximum Input Current (DC)
13A

Humidity Range
0-100%, condensing

Surge Protection
Integrated (Type II)

Frequency Range
50/60Hz (Automatic)

SUN-M40G4-EU-Q0-1 Deye 400W Single Phase Microinverter Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

Main Domestic Market
All India

SUN-M40G4-EU-Q0-1 Deye 400W Single Phase Microinverter About

Take advantage of a hot deal on the elite SUN-M40G4-EU-Q0-1 Deye 400W Single Phase Microinverter-an exceptional choice for both residential and commercial solar PV installations. With splendid integrated MPPT technology and top-tier efficiency of up to 96.5%, this microinverter enhances power conversion and ensures lofty performance in diverse environments. Personalise your solar experience with plug-and-play installation, real-time monitoring, and optional connectivity. Robust in safety, boasting protection functions and IP67 waterproofing for enduring reliability, this lightweight unit delivers high value and minimal maintenance for Indian traders, suppliers, and service providers.

Application Versatility & Key Features

Designed for rooftop and on-grid solar PV systems, the SUN-M40G4-EU-Q0-1 Deye 400W Microinverter is splendidly suited for both residential and commercial surfaces. It excels in places demanding high efficiency and robust safety, making it a top-tier solution for modern energy needs. Other notable features include rapid shutdown capability, IP67 waterproof protection, lightweight construction, natural convection cooling, and low-maintenance operation, all ensuring elite reliability and optimal solar output wherever installed.

Certifications, Payment, and Export Market Opportunities

Certified to meet EN 62109-1, EN 62109-2, and EN 61000 standards, this product guarantees international safety compliance vital for the global export market. Competitive payment terms and sample availability increase its market value among Indian traders. Freight can be arranged as per customer requirements, adding convenience and flexibility for buyers and suppliers alike. The SUN-M40G4-EU-Q0-1 is a highly valued export item for service providers targeting premium solar solutions.

FAQ's of SUN-M40G4-EU-Q0-1 Deye 400W Single Phase Microinverter:

Q: How does the integrated MPPT function benefit solar installations?

A: The integrated MPPT (Maximum Power Point Tracking) function ensures your solar modules operate under optimum voltage and current conditions, capturing maximum available power and greatly boosting overall system efficiency.

Q: What makes the SUN-M40G4-EU-Q0-1 suitable for both residential and commercial use?

A: Its scalable plug-and-play design, robust safety features, and high efficiency make it adaptable for any size of project, from small home installations to large commercial rooftops.

Q: Where can this microinverter be installed?

A: The microinverter is designed for on-grid and rooftop solar PV systems and is ideal for both indoor and outdoor environments due to its IP67 waterproof rating and wide operating temperature range.

Q: What is the process for monitoring the inverter's performance?

A: Performance can be monitored via a dedicated app, thanks to wireless communication and optional WiFi/PLC, allowing users to track and optimise their system in real time.

Q: When is sample availability offered to buyers?

A: Sample units can be requested as part of the purchasing process to evaluate compatibility and product fit before bulk procurement-especially beneficial for exporters and traders exploring new markets.
