Reliance 690W-720W Bifacial HJT Solar Panel RNE Pro-L Series Solar Panel

Name: Reliance 690W-720W Bifacial HJT Solar Panel RNE Pro-L Series Solar Panel
Brand: LAVANCHA RENEWABLE ENERGY PRIVATE LIMITED
Price: 14.99 INR
Availability: InStock

Price 14.99 INR/ Watt

Get a Price/Quote

MOQ : 10 Watts

Reliance 690W-720W Bifacial HJT Solar Panel RNE Pro-L Series Solar Panel Specification

Product Type
Bifacial HJT Solar Panel

Material
Glass/Glass with Aluminium Frame

Number of Cells
132 (6x22)

Operating Temperature
-40C to +85C

Max Voltage
730W (Voc: 49.0V, Isc: 18.7A)

Max System Voltage
1500V DC

Panel Efficiency
22.96% - 23.91%

Cable Length
400mm (+) / 400mm (-)

Number Of Diodes
3

Maximum Snow Load
5400 Pa

Size
1310mm x 2384mm

Dimension (L*W*H)
2384 x 1310 x 33 mm

Weight
39.5 kg

Color
Silver Frame

Connector Type
MC4 / MC4-EVO2 compatible

PID Resistance
Excellent (Anti-PID)

Cell Type
Monocrystalline Silicon, Half-Cut, N-Type

Fire Rating
Class C

Junction Box Rating
IP68, 25A

Packaging Configuration
31 pcs/pallet, 62 pcs/20'GP, 62 pcs/40'HC

Application
Utility Scale, Commercial and Industrial Rooftop

Bifaciality Factor
Up to 85%

Frame Thickness
33mm

Front Power Output Range
690W - 720W

Glass Thickness
2.0mm + 2.0mm (double glass)

Power Temperature Coefficient
-0.28%/C

Module Type
HJT (Heterojunction Technology)

Reliance 690W-720W Bifacial HJT Solar Panel RNE Pro-L Series Solar Panel Trade Information

Minimum Order Quantity
10 Watts

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Watts Per Month

Delivery Time
7 Days

Main Domestic Market
All India

Reliance 690W-720W Bifacial HJT Solar Panel RNE Pro-L Series Solar Panel About

Experience a triumphant leap in solar energy generation with the Reliance 690W-720W Bifacial HJT Solar Panel RNE Pro-L Series. Elevate your operations with this first-rate module featuring Heterojunction Technology (HJT) and a lavish bifaciality factor of up to 85%. Seize exclusive advance purchase promotions and offers for maximum returns. Featuring excellent PID resistance, fire rating Class C, and trusted in commercial, industrial, and utility applications, this module offers premium efficiency, robust durability, and exceptional adaptability - an unrivaled investment for those seeking top-tier performance.

Versatile Usage and Unrivaled Advantages

The Reliance 690W-720W Bifacial HJT Solar Panel RNE Pro-L Series is engineered for excellence in utility-scale, commercial, and industrial rooftop deployments. Its advanced bifacial design captures sunlight on both sides for amplified output, making it ideal for high-demand environments. With a remarkable efficiency of up to 23.91% and robust PID resistance, this panel provides a valuable edge over conventional modules, delivering consistent power and unwavering performance under diverse conditions.

Premium Supply Ability and Logistics

Reliance ensures a premium supply chain experience for the RNE Pro-L Series, efficiently handling every outlay and delivering goods transport nationwide. Sample policies facilitate product assessment upon request, ensuring client satisfaction before major commitments. Panels are securely packaged - 31 units per pallet and 62 per shipping container - guaranteeing safe transit and handling. This commitment to careful logistics and substantial supply capability underscores Reliance's dedication to quality delivery and client convenience.

FAQ's of Reliance 690W-720W Bifacial HJT Solar Panel RNE Pro-L Series Solar Panel:

Q: How does the bifacial HJT technology enhance panel performance?

A: The bifacial HJT technology allows the panel to capture sunlight from both the front and rear sides, significantly increasing energy yield. This innovative design can boost the power output by up to 85% compared to traditional panels.

Q: What are the recommended applications for the Reliance 690W-720W RNE Pro-L Series solar panel?

A: These panels are perfect for utility scale projects, large commercial installations, and industrial rooftop setups, offering robust and consistent performance across diverse operational environments.

Q: What is the process for advance purchase or acquiring a sample panel?

A: Advance purchase can be initiated through Reliance's official sales channels. Sample products may be requested for assessment, subject to the supplier's sample policy. Contact the provider directly to discuss sample availability and procurement details.

Q: Where is the Reliance RNE Pro-L Series solar panel supplied from, and is nationwide delivery supported?

A: These solar panels are supplied from India and Reliance offers nationwide goods transport, ensuring efficient delivery to commercial or industrial sites across the country.

Q: What are the primary competitive advantages of the RNE Pro-L Series?

A: The main advantages include superior efficiency up to 23.91%, advanced HJT bifaciality for greater energy output, excellent PID resistance, and a robust build featuring glass/glass construction and an IP68-rated junction box.
