Deye 15KW48V Sun Series Three Phase Hybrid Inverter, 2 MPPT, Low Valtage Battery Supported

Price 230657.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Deye 15KW48V Sun Series Three Phase Hybrid Inverter, 2 MPPT, Low Valtage Battery Supported Specification

Maintenance Type
Intelligent Air Cooling

Input Voltage
550 Volt (V)

Features
100% unbalanced output supported, max. 10 pcs parallel , max. charging/discharging current of 350A , 6 time periods for battery scheduling

Efficiency
97.6%

Material
NA

Number of Cells
0

Power
15000 Watt (w)

Operating Temperature
-40 to +60 C Celsius (oC)

Max Voltage
15000 Watt (W)

Max System Voltage
15000 Watt (W)

Output Voltage
230/400 Volt (V)

Cable Length
NA Millimeter (mm)

Switch Mode
Other

Size
456 750 268.5

Dimension (L*W*H)
456 750 268.5 Millimeter (mm)

Color
NA

Weight
51.9 Kilograms (kg)

Warranty
10 Year

Application
Commercial , Home, Industrial

Type Of Technology
Other

Installation Type
Other

Deye 15KW48V Sun Series Three Phase Hybrid Inverter, 2 MPPT, Low Valtage Battery Supported Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Telegraphic Transfer (T/T), Paypal

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

Sample Available
Yes

Packaging Details
national standard packaging

Main Domestic Market
All India

Certifications
Grid Regulation: IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002, OVE-Richtlinie R25, G99, VDE-AR-N 4105; Safety/EMC Standard: IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2

About Deye 15KW48V Sun Series Three Phase Hybrid Inverter, 2 MPPT, Low Valtage Battery Supported

Here is the professional description in English, broken into two comprehensive paragraphs:

High-Performance Power & Versatile Phase Management The Deye SUN-14/15/16/18/20K-SG05LP3 series represents a cutting-edge solution for modern three-phase solar energy systems. Designed with a unique 48V low-voltage battery architecture, it provides a safer and more cost-effective energy storage integration compared to high-voltage alternatives. A standout feature of this series is its 100% unbalanced output capability, allowing users to distribute up to 50% of the rated power on a single phase, which is essential for managing diverse household or commercial loads. With a massive charging and discharging current of up to 350A and a peak efficiency of 97.6%, this inverter ensures that your high-efficiency PV modules deliver maximum performance even under heavy demand.

Smart Integration & Robust Industrial Design Built for maximum flexibility, this hybrid inverter supports the parallel connection of up to 10 units, making it highly scalable for both on-grid and off-grid applications. It features an AC-coupling function that allows for easy retrofitting of existing solar installations, and it even supports storing energy directly from a diesel generator. The system is equipped with a sophisticated 6-stage time-period schedule for battery management, optimizing energy use and reducing grid dependence. Protected by an IP65-rated enclosure and featuring integrated Type II surge protection (AC/DC), the unit is engineered for long-term reliability in harsh environments, supported by smart monitoring options via Wi-Fi, GPRS, or LAN.
